Temporary turnstiles refer to a temporary installation and use of turnstile gates at entrances or exits for pedestrian management or security control. The turnstiles can be easily removed when no longer need to control the flow of people.
share:
Advantages Specifications

Temporary turnstiles Video:

What is temporary turnstiles?

Temporary turnstiles refer to a temporary installation and use of turnstile gates at entrances or exits for pedestrian management or security control. The turnstiles can be easily removed when no longer need to control the flow of people.

With a base and wheels, the temporary turnstiles can be moved freely to a safe point where the flow of people needs to be controlled, rather than being fixed in the same place. Fixed gates need to destroy the floor for wiring, while temporary gates do not. All the wires are hidden in the base, and the base can be moved at any time as needed, which is very convenient and flexible.

temporary turnstilestemporary turnstiles with wheel

No wiring, no digging, no damage to the floor, very easy to move make the temporary turnstile is an ideal solution for flexible crowd control.

Temporary turnstiles Installation Guide:

Temporary Turnstiles Applications:

Turnstiles enable effective traffic management and safety regulation. Turnstiles are appearing in an increasing number of locations as more people become aware of their advantages. Furthermore, various public spaces and institutions must manage crowds and reduce unnecessary visits in light of the early 2020 global Covid 19 outbreak. However, people want these regulations to be durable so that they can be removed when the outbreak gets better. As a result, "temporary turnstiles" are required.

They are also suitable for schools, factories, shopping malls, hospitals, etc. Taking schools as an example, at the school gate, at the peak of going to and from school, the traffic is huge, and administrators need to verify the identity of the entrants to ensure the safety of students. If you manually confirm one by one, it is very time-consuming and labor costs are high. Gates can automatically verify that visitors are authorized and allow very high volumes of traffic. For the rest of the time, administrators want the gates to be removed so that cars can enter the school. Temporary turnstiles are tailor-made for this purpose.

Temporary Turnstiles Dimension:

temporary turnstiles dimension

Temporary Turnstiles Features:


Runs smoothly, quietly and low energy consumption

Non-fixed movable base,can be removed once no longer needed;

No wiring and damage to the floor;


Automatically close if nobody enter within 5s(Can be set);

Auto open if any emergency or fire alarm;

Can be integrated with any type of access control systems;

Simple installation, easy operation and low maintenance;


Temporary Turnstiles Gallery:

Model No. MS02B
Cabinet Material SUS304/316 stainless steel
Arm Material SUS304/316 stainless steel
Unit Dimension(W*L*H) 1200*280*980mm
Passing Direction Uni-directional/Bi-directional
Photoelectric Sensor 4 pairs
Passage Width 600-900mm
Opening/Closing 0.5 seconds
Flow Rate 40-45 person/min
Mechanism

Absorption of electromagnet/Motor

Power Supply AC100-230V,50Hz
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 24 V
Application Indoor and outdoor(Shelter)
Working Temperature -25℃~+70℃
Operation Humidity 0 ~ 95% (No freeze)
MCBF 8,000,000 cycles
Anti-panic mode Automatically open when power off
Communication Dry contact, Relay signal, RS485
