Patent: MS07B
Optical Turnstiles MS07B is on the forefront of entrance and exit control with advanced innovation and user-friendliness. Its brushless motor-driven system ensures 8 millions opening and closing cycles, and is free from maintenance troubles.
share:
Advantages Specifications Dimension Options Gallery

Optical Turnstiles Descriptions:

Equipped with a large number of photoelectric switches to sensitively detect user behavior, optical turnstile will quickly open the physical barrier after receiving an effective door opening signal without making the user wait. Alternatively, if the photoelectric switch detects inappropriate behavior, such as forcibly entering without authorization, entering in the wrong direction, staying in the channel for more than a set time, etc., an audible and visual alarm will be triggered to urge the user to stop the inappropriate behavior, thereby Improve security in designated areas.

Optical Turnstiles Variations:

MS04Y optical turnstile can provide people with fast standard access lane (600mm) or wide lane (900mm) required by wheelchair users;
The stainless steel finish can be replaced with a more artistic powder-coated finish;
The spacious interior space can place various access control readers, such as biometric readers, QR code scanners, IC readers, etc., to meet the needs of different projects;
Active LED indicator color can be customized according to the brand logo;

Optical Turnstiles Applications:

The flexible channel width, sensitive detection components, modern fashion design and extremely high throughput make the MS04Y optical turnstiles suitable for use in luxury commercial buildings, corporate headquarters, public facilities, cultural centers, public transportation hubs, educational institutions, and fitness centers and many more applicaitons.




Photoelectric sensors detects including unauthorized entry, tailgating , illegal intrusion, reverse intrusion, etc;

Automatic reset functio;n: swing arms will lock automatically if nobody enter within 5s(Can be set);

Passage width from 500-900mm,suitable for disabled and trolley access;

Swing barriers run smoothly with lose noise system;

With anti-collision movement, swing barriers will reset automatically if they are strong hit by bicycle or trolley;

Can be integrated with any type of access control systems;

Simple installation, operation and maintenance;
Model No. MS07B
Cabinet Material SUS304/316 stainless steel
Swing Material Plexi-glass or Tempered glass
Unit Dimension(W*L*H) 1400*185*980mm
Passing Direction Uni-directional/Bi-directional
Photoelectric Sensor 6 pairs(2 for protecting children)
Passage Width 600-900mm
Opening/Closing 0.6 seconds
Flow Rate 40-45 person/min
Mechanism Brushless or servo motor
Power Supply AC100-230V,50Hz
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 24 V
Application Indoor and outdoor(Shelter)
Working Temperature -25℃~+70℃
Operation Humidity 0 ~ 95% (No freeze)
MCBF 8,000,000 cycles
Anti-panic mode Automatically open when power off
Communication Dry contact, Relay signal, RS485
Flexible configurations available optionally up on request.
01 Cabinet Material
Generally cabinets are made from brushed 304 stainless steel.
The following materials are also available:
02 Cabinet Anti-fingerprint process
Anti-fingerprint steel treatment is based on the original 304 stainless steel, after vacuum coating, forming a layer of bright protective film on the surface also has the function of anti-fingerprint.
03 Cabinet Colors
In addition to the primary color of stainless steel, you can also choose other colors, such as white, black, brown, etc., to make it more coordinated with your building.
04 Glass Etching
Support personalize glass barriers and side panels with etched artwork, logos or directions.
05 Panels Material
You can select plexi-glass or tempered glass for swing panels and/or filter panels.
06 Mechanism
Configured brushless motor by default.
You can choose to upgrade it with servo motor, make it perform even better beyond your expect.
High swing arm(ground clearance≥1.2meter) configured servo motor by default.
07 Custom Illumination
Besides regular LED indicator, static or dynamic lightings hidden in the glass panels are also optional ,which meets the different needs of various occasions.
*More options and customizations available on request.
