Patent: MS04S
As a professional access product for commercial office buildings and office halls of government agencies, Fastlane Turnstile MS04S speed gate has made innovations and breakthroughs in manufacturing technology, electronic control technology, and detection
share:
Advantages Specifications Dimension Options Gallery

Fastlane Turnstile Video:

Fastlane Turnstile Description:

Fastlane turnstile is also called speed gate, it is a high-tech turnstile gate with a trendy appearance and ultra-short opening time for guiding the flow of people and enhancing security at entry points.
Open appearance, slender footprint, ultra-fast door opening speed, and innovative design-all of these make many customers give priority to MS04S when choosing fastlane turnstiles. With infrared sensors in the channel, people and objects can be reliably detected without any physical contact, which protects user privacy and ensures security.

Fastlane Turnstile Installation Guide:

Fastlane Turnstile Installation Variations:

The height of the glass can be adjusted according to the security level of the building, from standard 0.9 meter to full height 1.8 meter.
Users can be granted access rights by various access control systems, including but not limited to face recognition, barcode scanning, fingerprint scanning, password locks, and more.
The standard lane width of fastlane is 0.6 meter, or the barrier-free lane is 0.9 meter for users in wheelchairs or strollers.

Fastlane Turnstile Applications:

In addition to its bright, exquisite, and fashionable exterior design, the interior of MS04S fastlane turnstile features an industry-leading servo-controlled motor and movement for accurate and quick positioning. It is one of the most slender and elegant turnstile gates in the industry. Therefore, MS04S is widely used in various high-end occasions, such as cultural institutions, commercial buildings, corporate headquarters, large shopping malls, art centers, etc.

Fastlane Turnstile Features:


Narrow and fasional design;

Photoelectric sensors detects including unauthorized entry, tailgating , illegal intrusion, reverse intrusion, etc;

With servo brushless motor, MCBF of it up to 10 millions;

Different heights of glass available to prevent pedestrians from climbing over;

Short opening time of 0.3 seconds for a high throughflow frequency;

Audible & visible alerts when detect unauthorized entry;

Passage width from 600-900mm, suitable for wheelchairs and prams;

Various LED indicators clearly show the passage direction and status;

Can be integrated with any type of access control systems;

Simple installation, operation and maintenance;



Model No. MS04S
Cabinet Material SUS304/316 stainless steel
Swing Material Plexi-glass or Tempered glass
Unit Dimension(W*L*H) 1500*125*1000mm
Glass height(from floor) 900-1600mm
Passing Direction Uni-directional/Bi-directional
Photoelectric Sensor 8 pairs
Passage Width 600-900mm
Opening/Closing 0.3 seconds
Flow Rate 45-50 person/min
Mechanism Brushless motor/Servo motor
Power Supply AC100-230V,50Hz
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 24 V
Application Indoor and outdoor(Shelter)
Working Temperature -25℃~+70℃
Operation Humidity 0 ~ 95% (No freeze)
MCBF 10,000,000 cycles
Anti-panic mode Automatically open when power off
Communication Dry contact, Relay signal, RS485
Fastlane Turnstile Speed Gate dimension
Flexible configurations available optionally up on request.

01 Cabinet Material
Generally cabinets are made from brushed 304 stainless steel.
The following materials are also available:
02 Cabinet Anti-fingerprint process
Anti-fingerprint steel treatment is based on the original 304 stainless steel, after vacuum coating, forming a layer of bright protective film on the surface also has the function of anti-fingerprint.
03 Cabinet Colors
In addition to the primary color of stainless steel, you can also choose other colors, such as white, black, brown, etc., to make it more coordinated with your building.
04 Glass Etching
Support personalize glass barriers and side panels with etched artwork, logos or directions.
05 Panels Material
You can select plexi-glass or tempered glass for swing panels and/or filter panels.
06 Mechanism
Configured brushless motor by default.
You can choose to upgrade it with servo motor, make it perform even better beyond your expect.
High swing arm(ground clearance≥1.2meter) configured servo motor by default.
07 Custom Illumination
Besides regular LED indicator, static or dynamic lightings hidden in the glass panels are also optional ,which meets the different needs of various occasions.
*More options and customizations available on request.
