Patent: MS11G
Turnstile with face recognition refers to security turnstile combined with face recognition terminals to provide users with contactless access, improve safety factor and user-friendliness.
share:
Advantages Specifications

Turnstile With Face Recognition Video:

Turnstile With Face Recognition Description:

Turnstile with face recognition refers to security turnstile combined with face recognition terminals to provide users with contactless access, improved security and high user-friendliness.
The face recognition terminal collects the facial information of passers-by and compares it with the information in the database. If the comparison matches, the door opening signal will be sent to the turnstile to allow entry, otherwise the entry will be refused.
with the feaures of high speed, high accuracy, no contact, anti-theft brush, less loss, and good system scalability, making face recognition the trend of today's entry control.

Turnstile With Face Recognition Installation Guide:

Turnstile With Face Recognition Variations:

Face recognition turnstiles are not limited to a certain gate, but all waist high turnstiles, optical turnstiles and full height turnstiles are compatible with face recognition terminals;

It also supports embedded temperature measurement modules to detect the body temperature of passers-by, which is of great significance in the era of epidemics and can effectively filter people with fever;

Turnstile With Face Recognition Applications:

The face recognition system that integrates time recording, staff scheduling, and visitor management is more and more frequently used in various occasions, including school entrances, dormitory buildings, libraries, restaurants, residential quarters, offices, clubs, fitness centers, and transportation hubs, etc.

Turnstile With Face Recognition Dimension:

Turnstile with Face Recognition
Model No. MS011G
Cabinet Material SUS304/316 stainless steel
Arm Material SUS304/316 stainless steel
Unit Dimension(W*L*H) 1200*280*980mm
Passing Direction Uni-directional/Bi-directional
Photoelectric Sensor None
Passage Width 550mm
Opening/Closing 0.5 seconds
Flow Rate 30-35 person/min
Mechanism

Absorption of electromagnet/Motor

Power Supply AC100-230V,50Hz
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 24 V
Application Indoor and outdoor(Shelter)
Working Temperature -25℃~+70℃
Operation Humidity 0 ~ 95% (No freeze)
MCBF 8,000,000 cycles
Anti-panic mode Automatically open when power off
Communication Dry contact, Relay signal, RS485
